Nokia FastMile 5G Gateway 3.1
The Nokia FastMile 5G Gateway 3.1 (Model: 5G12-13W-B) is a high-performance indoor 5G CPE (Customer Premises Equipment) router designed to deliver ultra-fast fixed wireless broadband connectivity. The Nokia FastMile 5G Gateway 3.1 combines Qualcomm Snapdragon X55 5G modem technology, Wi-Fi 6 AX3600 networking, advanced antenna systems, touchscreen management, and enterprise-grade routing features into a compact and powerful smart gateway solution.
The Nokia FastMile 5G Gateway 3.1 is engineered to provide reliable high-speed internet access for homes, offices, smart environments, and fixed wireless access (FWA) deployments using both 5G NR and 4G LTE mobile networks.
General Specifications
| Specification | Details |
|---|---|
| Product Name | Nokia FastMile 5G Gateway 3.1 |
| Model | 5G12-13W-B |
| Product Type | 5G Gateway / CPE Router |
| Manufacturer | Nokia |
| Network Support | 5G NR / LTE / Wi-Fi 6 |
| SIM Type | 4FF Nano SIM |
| Power Input | 12V DC |
| Power Consumption | Less than 36W |
Processor and Chipset
Qualcomm Snapdragon X55 5G Modem
The Nokia FastMile 5G Gateway 3.1 is powered by the Qualcomm Snapdragon X55 modem platform, providing advanced 5G and LTE connectivity.
Supported technologies include:
- 5G NR NSA (Non-Standalone)
- 5G NR SA (Standalone)
- Gigabit LTE fallback
- Advanced carrier aggregation
- High-speed mobile broadband
- Low latency networking
The Snapdragon X55 platform provides:
- Improved spectral efficiency
- Better signal processing
- Enhanced throughput
- Stable multi-band aggregation
- Reliable broadband performance
Qualcomm IPQ8072A Networking Processor
The Nokia FastMile 5G Gateway 3.1 incorporates the Qualcomm IPQ8072A networking processor to handle Wi-Fi and routing operations.
Key functions include:
- Wi-Fi 6 processing
- MU-MIMO support
- High client-density networking
- Smart traffic management
- Multi-gigabit routing performance
The IPQ8072A chipset is optimized for demanding home and business networking environments.
5G Network Support
5G NR NSA Bands
The Nokia FastMile 5G Gateway 3.1 supports the following NSA bands:
- n1
- n3
- n7
- n8
- n20
- n28
- n38
- n40
- n41
- n66
- n77
- n78
5G NR SA Bands
Supported SA bands include:
- n1
- n3
- n7
- n8
- n20
- n28
- n38
- n40
- n41
- n66
- n77
- n78
The Nokia FastMile 5G Gateway 3.1 supports both Standalone (SA) and Non-Standalone (NSA) 5G architectures, ensuring compatibility with current and future operator deployments worldwide.
LTE Specifications
LTE Bands
The Nokia FastMile 5G Gateway 3.1 supports:
- B1
- B2
- B3
- B4
- B5
- B7
- B8
- B12
- B20
- B25
- B28
- B32
- B38
- B40
- B41
- B42
- B66
LTE 4×4 MIMO Bands
Supported LTE 4×4 MIMO bands:
- B1
- B2
- B3
- B4
- B7
- B25
- B32
- B38
- B40
- B41
- B42
- B66
Benefits of 4×4 MIMO include:
- Improved signal quality
- Faster download speeds
- Increased capacity
- Enhanced network stability
LTE Category
| Feature | Specification |
|---|---|
| LTE Download Category | Cat 20 |
| LTE Upload Category | Cat 18 |
LTE Modulation
| Feature | Specification |
|---|---|
| Downlink Modulation | 256QAM |
| Uplink Modulation | 256QAM |
Higher-order modulation improves:
- Throughput
- Spectrum efficiency
- Data capacity
LTE Maximum Speed
| Direction | Maximum Speed |
|---|---|
| Download | Up to 2000 Mbps |
| Upload | Up to 200 Mbps |
Wi-Fi Specifications
Wi-Fi 6 AX3600
The Nokia FastMile 5G Gateway 3.1 supports Wi-Fi 6 (802.11ax) technology with AX3600 wireless performance.
Maximum wireless throughput:
- Up to 3.6 Gbps
Supported Wi-Fi Standards
- 802.11a
- 802.11b
- 802.11g
- 802.11n
- 802.11ac
- 802.11ax
The Nokia FastMile 5G Gateway 3.1 provides compatibility with:
- Legacy Wi-Fi devices
- Wi-Fi 6 clients
- Smart home products
- Gaming systems
- IoT devices
Dual-Band Wireless
Supported frequencies:
- 2.4 GHz
- 5 GHz
Wireless features include:
- MU-MIMO
- Wi-Fi Multimedia (WMM)
- Channel bandwidth selection
- Transmission power control
- Multiple SSIDs
- Wi-Fi scheduling
- Wireless encryption management
The WebUI offers both Basic and Advanced wireless configuration modes.
Device Capacity
Connected Devices
The Nokia FastMile 5G Gateway 3.1 supports:
- Up to 128 connected devices
Ideal for:
- Large households
- Smart homes
- Small businesses
- Office environments
- IoT deployments
- High-density wireless usage
Antenna System
5G NR Antenna Gain
High-Band 5G
n7 / n38 / n40 / n41 / n77 / n78
- 3–6.5 dBi
Mid-Band 5G
n1 / n3 / n66
- 3–4 dBi
Low-Band 5G
n8 / n20 / n28
- 0–2 dBi
LTE Antenna Gain
High LTE Bands
B7 / B38 / B40 / B41 / B42
- 3–5 dBi
Mid LTE Bands
B1 / B3 / B2 / B25 / B4 / B66 / B32
- 2–4 dBi
Low LTE Bands
B5 / B8 / B12 / B28 / B20
- 0–2 dBi
The omni-directional antenna system of the Nokia FastMile 5G Gateway 3.1 helps improve:
- Indoor reception
- Signal stability
- Broadband performance
- Network coverage
For best performance, Nokia recommends placing the gateway near a window.
Display and User Interface
LCD Display
The Nokia FastMile 5G Gateway 3.1 includes an integrated LCD display for:
- Signal visualization
- Connection monitoring
- Device status information
- Network diagnostics
Touchscreen Controls
The built-in touchscreen provides:
- Local device management
- Quick status access
- Interactive navigation
- Direct configuration controls
Users can manage key gateway functions without accessing the WebUI.
Ethernet and Wired Connectivity
Gigabit Ethernet
The Nokia FastMile 5G Gateway 3.1 includes:
- 2 × Gigabit Ethernet ports
Supports:
- Desktop computers
- Smart TVs
- Gaming consoles
- NAS systems
- Ethernet switches
One Ethernet port is labeled WAN but currently operates as a LAN port in most firmware versions.
Voice Connectivity
The Nokia FastMile 5G Gateway 3.1 includes:
- 1 × RJ11 TEL port
Supports:
- Voice over LTE (VoLTE)
- Telephone devices
- Fixed wireless voice services
Voice status can be monitored through the WebUI.
WebUI Management
The Nokia FastMile 5G Gateway 3.1 provides a browser-based WebUI for:
- Device configuration
- Network diagnostics
- Monitoring
- Security management
- Firmware updates
Supported browsers:
- Google Chrome
- Microsoft Edge
- Mozilla Firefox
- Apple Safari
Default management address:
Advanced Features
Network Features
The Nokia FastMile 5G Gateway 3.1 supports:
- DHCP
- Static DHCP
- IPv4
- IPv6
- APN management
- Static routes
- Connected device monitoring
Security Features
Security capabilities include:
- Firewall protection
- Attack protection
- IP filtering
- ALG support
- DMZ functionality
Supported ALG protocols:
- FTP
- TFTP
- SIP
- H323
- RTSP
- L2TP
- IPSEC
- PPTP
Diagnostics and Maintenance
Built-in diagnostic tools include:
- System logging
- Signal monitoring
- Network statistics
- Ookla speed testing
Speed tests provide:
- Download speed
- Upload speed
- Latency
- Jitter
- Server location
Physical Specifications
| Specification | Details |
|---|---|
| Diameter | 125 mm |
| Height | 218.5 mm |
| Weight | Less than 1400 g |
The cylindrical design of the Nokia FastMile 5G Gateway 3.1 improves:
- Signal propagation
- Heat dissipation
- Indoor aesthetics
- Device stability
Key Advantages
Major Benefits
- Qualcomm Snapdragon X55 modem
- Wi-Fi 6 AX3600 technology
- 5G NSA and SA support
- Touchscreen LCD display
- Up to 128 connected devices
- Gigabit Ethernet connectivity
- Advanced antenna system
- Enterprise-grade security
- Integrated diagnostics
- Strong indoor 5G performance
Ideal Applications
The Nokia FastMile 5G Gateway 3.1 is ideal for:
- Home broadband replacement
- Smart homes
- Remote work environments
- Online gaming
- 4K and 8K streaming
- Small business networking
- Fixed wireless access deployments
- Enterprise connectivity
- IoT environments
The Nokia FastMile 5G Gateway 3.1 combines advanced 5G connectivity, Wi-Fi 6 performance, enterprise networking features, and intelligent management tools to deliver a powerful fixed wireless broadband solution for modern homes and businesses.
